Item	15inch 1024x768 LCD display
Model No	PV15002YH20C
Resolution	1024x768 / XGA
Outline Dimension	326.5(W)×253.5(H)×9.1(T)
Active Area(mm)	304.1 (H) x 228.1(V)
Interface	LVDS
Brightness	350nits
Viewing Angle	All
LED life	70000h
Display Mode	TN / Transmissive / Normally Black
PIN	20
Operating Temperature	-30℃~70℃
Storage Temperature	-40℃~70℃
Touchscreen	Can custom capacitive touchscreen

15-PV15002YH20C

Specification of 15-PV15002YH20C

Application of 15-PV15002YH20C
