5.7-PV05709D0140K-R

  • pv05709d0140k r 01
  • pv05709d0140k r 02
  • pv05709d0140k r 01
  • pv05709d0140k r 02

PV05709D0140K-R is Kingtech 5.7 inch LCD module using IPS TFT-LCD technology.Its resolution is 640x480dots, providing a very clear and vivid image.With Full Viewing angle, you can see clearly the display from different direction.Its driver ic is JD9168S, supports RGB interface. Its brightness can reach 500nits. It has a compatible resistive touch. So we can provide Single LCD module or LCD module with RTP. Kingtech supports stable supply.And we support LCD display related customization,such as FPC , Backlight, Touch, Cover glass, driver board,etc


Features of 5.7-PV05709D0140K-R

  • Landscape

  • 640x480

  • 5.7inch

  • All viewing angle

  • A compatible resistive touch panel optional


Specification of 5.7-PV05709D0140K-R


Item 5.7 inch IPS 600x480 LCD module with Resistive touch
Model No.PV05709D0140K-R
Resolution 640*480
Outline Dimension (mm)127.00*98.43*7.5
Active Area (mm)115.20*86.40
Viewing AngleAll
Brightness500nits
Interface RGB
Backlight3*7LED
Pin nums40
Driving IC JD9168S
Operating Temperature -20℃~70℃
Storage Temperature -30℃~80℃
Touch screenResistive touch
ApplicationMedical,Industrial,Consumer,Handheld device,Smart Home


Application of 5.7-PV05709D0140K-R


  • It is applicable for Medical,Industrial,Consumer,Handheld device,Smart Home.
