Kingtech 3.5 inch 320*480 IPS TFT module display supply very stable. This 3.5 inch tft screen supports MCU interface. In addition, this 3.5 inch IPS LCD screen is All viewing type/full/wide/IPS viewing angle. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
Stable supply
Full/Wide/All viewing angle
Can custom resistive touch and capacitive touch
Get a Quote
Documentation
| Item | 3.5inch IPS 320*480 TFT display |
| Model No. | PV03522H0139V |
| Resolution | 320*480 |
| Outline Dimension (mm) | 54.46*82.94*2 |
| Active Area (mm) | 48.96*73.44 |
| Viewing Angle | All |
| Brightness | / |
| Interface | MCU |
| Backlight | 6*1LED |
| Driving IC | ST7796 |
| PIN No. | 39 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, medical, hand-held device, industrial, smart home |
The 3.5 inch 320*480 TFT display module can be used for Medical, E-bike, forklift, hand-held device, industrial, thermostat or others.
