6.01-DW60QVSA11H1FQ

  • dw60qvsa11h1fq 01
  • dw60qvsa11h1fq 02
  • dw60qvsa11h1fq 01
  • dw60qvsa11h1fq 02

Kingtech DW60QVSA11H1FQ-CO is 6.01 inch Amoled display module. Resolution is 1080*2160, providing a very clear and vivid image.With Full Viewing angle, you can see clearly the display from different direction.It supporst MIPI interface, fast tranmission speed. Its brightness can reach 450nits. Capacitive touch is optional. Amoled omit automatically with bright image performance.Kingtech supports stable supply.And we support LCD display related customization,such as FPC , Backlight, Touch, Cover glass, driver board,etc


Features of 6.01-DW60QVSA11H1FQ


  • Amoled,Bright display performance

  • High resolution 1080x2160

  • 6.01inch big size

  • MIPI interface

  • Full Viewing angle

  • Designed for phone


Specification of 6.01-DW60QVSA11H1FQ


Item 6.01 inch 1080x2160 Amoled with Capacitive touch
Model No.DW60QVSA11H1FQ
Resolution 1080*2160
Outline Dimension (mm)74.03*155.36*2.47
Active Area (mm)68.256*136.512
Viewing AngleAll
Brightness450nits
Interface MIPI Interface
Backlight
Pin nums40
Driving IC CH13721C
Operating Temperature -20℃~70℃
Storage Temperature -30℃~80℃
Touch screenCapacitive touch
ApplicationPhone,Medical,Industrial,Tablet,Handheld device


Application of 6.01-DW60QVSA11H1FQ


  • It is applicable for Phone,high end product, Industrial,Medical,Handheld device.
