Kingtech 4.3 inch 480*272 TFT display supply very stable. This 4.3 inch supports MCU interface. In addition, the 4.3 inch 480*272 TFT display module brightness is 260 nits, and this 4.3 inch WQVGA display is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.
4.3 inchTFT display
480*272/WQVGA
Stable supply
All/Full/Wide/IPS viewing angle
MCU interface
260nits brightness/Sunlight readable/High brightness
Can custom resistive touch and capacitive touch
Medical, hand-held device, industrial
Get a Quote
Documentation
| Item | 4.3 inch IPS 480*272 TFT display |
| Model No. | PV043022H0130X |
| Resolution | 480*272 |
| Outline Dimension (mm) | 105.5*67.2*2.95 |
| Active Area (mm) | 95.04*53.86 |
| Viewing Angle | All |
| Brightness | 260nits |
| Interface | MCU |
| Backlight | 7*1LED |
| Driving IC | / |
| PIN No. | 30 |
| Operating Temperature | -20~70C |
| Storage Temperature | -30~80C |
| Touch screen | Can custom resistive and capacitive touch screen |
| Application | E-Bike, Medical, hand-held device, industrial |
The 4.3 inch 480*272 TFT display module can be used for E-Bike, Medical, hand-held device, industrial or others.
