Kingtech 5.7inch 640x480 TFT LCD module display supply is very stable. This 5.7 inch supports an 18-BIT RGB interface. In addition, the 5.7 inch TFT display brightness is 560nits, high brightness, sunlight readable, and outdoor, and this 5.7-inch screen is 6 O’CLOCK/ TN viewing angle type. For the touch part, this is a resistive touch screen and we also can customize the touch screen according to the customer's requirements.
TFT display
640*480
Stable supply
560 nits/high brightness/sunlight readable/Outdoor
TN/6 O'CLOCK viewing angle
18-BIT RGB interface
Medical/industrial
Resistive touch screen
Get a Quote
Documentation
| Item | 5.7 inch 640*480 display with resistive touch |
| Model No | PV05703YP40D-R |
| Resolution | 640*480 |
| Outline Dimension | 127.00*98.43*9.20 |
| Active Area(mm) | 115.20*86.40 |
| Brightness | 560nits |
| Viewing Angle | 6 O’CLOCK |
| Interface | 18-BIT RGB |
| Driving IC | HX8250-A01*2+HX8678A |
| Operating Temperature | -20℃~70℃ |
| Storage Temperature | -30℃~80℃ |
| Touch screen | Resistive touch |
The 5.7 inch 640*480 TFT display module can be used for medical, industrial products, and others.
