Kingtech 27'' inch 1920*1080 TFT module display supply very stable. This 27'' inch supports LVDS interface. In addition, the 27'' inch TFT display module brightness is 400nits, and this 27''  inch screen is All viewing type. For the touch part, we can also customize capacitive and resistive touch according to the customer requirements.

Features of 27-PV02701S0730C

  • Stable supply

  • Can custom resistive touch and capacitive touch

  • High Color Saturation: 72% NTSC

  • High Contrast Ratio: 4000:1

  • FHD Resolution (1920 x 1080)

Specification of 27-PV02701S0730C

Item 27'' IPS 1920*1080 TFT display
Model No.PV02701S0730C
Resolution 1920*1080
Outline Dimension (mm)630*368.2*13
Active Area (mm)597.88*336.312
Viewing AngleAll
Interface LVDS
Driving IC /
PIN No.30
Operating Temperature -20-70C
Storage Temperature -30~80C
Touch screenCan custom resistive and capacitive touch screen
ApplicationE-Bike, Medical, hand-held device, industrial

Application of 27-PV02701S0730C

  • The 27'' inch 1920*1080 TFT display module can be used for Medical, hand-held device, industrial, outdoor, Elevator, Access Control device, advertising and others.
